UK RCD Plastic Clad Switched Fused Spur Connection Unit

0130FPW (RCD fuse unti,PC Clad)

Specification

Rated Voltage: 240VAC

Rated Current: 13A max

Frequency: 50Hz

Tripping current: 10mA & 30mA

Tripping speed: 40mS max

Voltage Surge: 4K(100KHz Ring Wave)

Endurance: 3000 Cycles min

Hit-Pot: 20oov min

Approval: CE&BS

Cable capacity: 1.25~1.5 m

IP Rating: IP4X

Dimension: 86*86mm

Application: Equipment, Household appliances, etc.

0130FPW (RCD fuse spur unti, PC Clad)

Specification

Rated Voltage: 240VAC

Rated Current: 13A max

Frequency: 50Hz

voltage Surge: 4K (100KHz Ring Wave)

Endurance: 15000 Cycles min

Hit-Pot: 200ov minute

Approval: CE&BS

Cable capacity: 5X2.5 mm3 max

lp Rating: IP4X

Application:

Equipment, Household appliances, etc.

WHAT IS RCD Socket & Plug?

A residual-current device (RCD), or residual-current circuit breaker (RCCB), is a device that instantly breaks an electric circuit to prevent serious harm from an ongoing electric shock. Injury may still occur in some cases, for example if a human falls after receiving a shock. In the United States and Canada, the device is more commonly known as a ground fault circuit interrupter (GFCI), ground fault interrupter (GFI) or an appliance leakage current interrupter (ALCI). In the United Kingdom, these are better known by their initials RCD, and a combined RCD+MCB (miniature circuit breaker) is known as a RCBO (residual-current circuit breaker with overcurrent protection). In Australia, they are sometimes known as safety switches or an RCD. An earth leakage circuit breaker (ELCB) may be a residual-current device, although an older type of voltage-operated earth leakage circuit breaker also exists.
