HW76 BULK ULTRASONIC WATER METER

(Al Alloy meter head, double pipes, without diameter minificatioDouble pipes measuring, high acouracy and reliability
Redundant,the meter can operate properly when thereis blockage or fault wath one of the two pipes
Smart alarm of fiow Sensor error, temperature sensor error short circuit, overload, low battery
Patented flow measuring method and and smart data error correcting technology, super accuracy and stability.
Availability:
Inquire Add to Basket

  • HW76

  • Yuanky

  • America

MODEL

Normina Diameter

 Pormanent Flow Rate Transitional Flow Rate Minimum Flow Rate Flange Diameter Meter Length Connection Bolt
DN(mm) Q 3(m3/h) Q 2(m3/h) Q 1(m3/h) (mm) (mm)
DN300 300 1400 17.9 11.2 520 550 16*M24
DN400 400 1600 20.5 12.8 580 600 16*M27
DN450 450 2000 25.6 16 640 650 20*M27
DN500 500 2500 32 20 705 650 20*M30
Param-eters

Accuracy : 2%      Temperature Class :T30         Pressure Class: MAP16        Pressure Loss Class: △p40

Ambient Class: Class O             Protection Class: IP68       EMC Level : E1        Installation Mode: H/V

Flow Section Sensitivity Level: U5/D3    Dynamic Range:125      Pipe Material: Cast Stee!





water meter Ultrasonic Water Meter BULK ULTRASONIC WATER METER
