NT54-32 double bracket safety breaker

NT54-32 double bracket safety breaker strictly follows original design and adopt high-end material. It is specially designed for high-level using situation. The breaker works in lining of 50/60Hz with rated current up to 30A with superior performance. The product complies with international IEC 60898 standard.
Availability:
Inquire Add to Basket

  • NT54-32

  • Yuanky

  • America

Frame current, Inm (A) 30AF
Type NT54-32
Pole & element 2P1E
Rated insulating voltage, Uimp (kV) 2.5
Rated current, In (A) 10,15,20,30
Rated working Voltage, Ue (V) AC230/110
Breaking capacity, Ic (A) 1500
Overload characteristics 1.13 In(cold state) not acting time +30℃,≥1h
1.45 In(heat state) acting time +30℃,＜1h
2.55 In(cold state) acting time 1s<t<60s





safety breaker bracket safety breaker double bracket safety breaker
