HW68 BULK ULTRASONIC WATER METER

1.Double pipes measuring, high accuracy and reliability. Redundant,the meter can operate properly when thereis blockage or fault with one of the two pipesSmart alarm of flow Sensor error, temperature sensor error shortcircuit, overload, low batteryPatented flow measuring method and and smart data error correcting technology, super accuracy and stability.

2.Four pipes measuring, high accuracy and reliability.Redundant,the meter can operate properly when there is blockage or fault with one of the two pipesSmart alarm of fiow Sensor error, temperature sensor error,short circuit, overload, low batteryPatented flow measuring method and and smart data error correctingtechnology, super accuracy and stability.

Availability:



Inquire Add to Basket

Model:
HW68
Brand:
Yuanky
Intercontinental Product:
America

Product Description

MODEL	Normina Diameter	Pormanent Flow Rate	Transitional Flow Rate	Minimum Flow Rate	Flange Diameter	Meter Length	Connection Bolt
MODEL	DN(mm)	Q ₃(m³/h)	Q ₂(m³/h)	Q ₁(m³/h)	(mm)	(mm)
DN50	50	25	0.20	0.125	165	200	4*M16
DN65	65	40	0.32	0.200	185	200	4*M16
DN80	80	63	0.50	0.315	200	225	8*M16
DN100	100	100	0.80	0.500	220	250	8*M16
DN125	125	160	1.25	0.800	250	250	8*M16
DN150	150	250	2.0	1.250	285	300	8*M20
DN200	200	400	3.20	2.000	340	350	12*M20
DN250	250	630	5.00	3.150	450	450	12*M24
DN300	300	1000	8.00	5.000	500	500	12*M24
Param-eters	Accuracy : 2% Temperature Class :T30 Pressure Class: MAP16 Pressure Loss Class: △p40 Ambient Class: Class O Protection Class: IP68 EMC Level : E1 Installation Mode: H/V Flow Section Sensitivity Level: U5/D3 Dynamic Range:125-400 Pressure Resolution: 0.1MPa Pressure Measuring Range: (0-1.6)MPa
