C7 (TL) Series AC Contactor

Model and implication

Note1

09A-32Ain the form of auxiary contacts

10 represents three nomally open main contacts and one nomaly open auiliary contac(32A and below);

01 represents three nomally open main contacts and one normally closed aullay contact(32Aand below);,

11 represents three nomly open main contacts cone nomally open and one nomally cdosed auoliary contacts(40A and above);

40 epresents the four romaly open main contact,08 means BMO nomally open and two nomaly dosed main contats
