HWS Series Contactor

Availability:
Inquire Add to Basket

  • America

TYPE HWS-T10 HWS-T12 HWS-T20 HWS-T21 HWS-T25
KWHP(AC1-3
Rated powerlAC-3)
IEC60947-4		 220V 2.2 2.7 3.7 4 5.5
380V 2.7 4 7.5 7.5 11
Rated operoted
current(AC-3)
GB14048.4		 220V 11 13 18 20 26
380V 7 9 18 20 25
Conventional thermol current(Al 20 20 20 32 32
Rated insulated voltage(V 690
Auxiliary
contoct
[AC-15]
Standard 1NO 1NO+1NC 2NO+2NC
Roted
current/A		 120V 6
220V 3
Electrical life 200
Mechanical life 1000
Overall dimension 36x75×78 43×75×78 63x81x81
Installaton dimension 28×60 35×60 54x60
Control coil
roted voltogeV)
50/60Hz		 AC24V 24
AC48V 48-50
AC100V 100~127
AC200V 200~240
AC30V 260~300
AC400V 380-400
AC500V 460-550


HWS Series Contactor A.C.contactor DC Contactor ac dc contactor 24v Dc Contactor
