Metal Enlarger

Application:An enlarger is used if the dimensions of existing tapped holes are
too large for a given gland.It provides a means of connection
between cable entry devices and equipment having dissmilar
threads

Availability:



Inquire Add to Basket

Brand:
YUANKY
Intercontinental Product:
America

Product Description

◆Material:Brass,nickel plated or Brass,chrome plated

◆Application:An enlarger is used if the dimensions of existing tapped holes are

too large for a given gland.It provides a means of connection

between cable entry devices and equipment having dissmilar

threads

◆Accessories:Locknut,Sealing Washer

六角系列 Hexagon	圆形系列 Circle	外螺纹(D1) Outer Thread	内螺纹(D2) Inner Thread	螺纹长度(GL) Thread Length	高度(H) Height	扳手径(D) Spanner Size
HW-ENM12/16H	HW-ENM12/16C	M12×1.5	M16×1.5	6	10.5	18
HW-ENM16/20H	HW-ENM16/20C	M16×1.5	M20×1.5	6.5	10.5	24
HW-ENM20/25H	HW-ENM20/25C	M20×1.5	M25×1.5	7.5	11.5	27
HW-ENM25/32H	HW-ENM25/32C	M25×1.5	M32×1.5	8	12	35.5
HW-ENM32/40H	HW-ENM32/40C	M32×1.5	M40×1.5	9	13	43
HW-ENM40/50H	HW-ENM40/50C	M40×1.5	M50×1.5	10	16	55
HW-ENM50/63H	HW-ENM50/63C	M50×1.5	M63×1.5	10	17	70
HW-ENPG7/9H	HW-ENPG719C	PG7	PG9	6	10.5	18
HW-ENPG9/11H	HW-ENPG9/11C	PG9	PG11	6.5	10.5	20
HW-ENPG11/13.5H	HW-ENPG11/13.5C	PG11	PG13.5	6.5	10.5	22
HW-ENPG13.5/16H	HW-ENPG13.5/16C	PG13.5	PG16	6.5	11	24
HW-ENPG16/21H	HW-ENPG16/21C	PG16	PG21	7.5	11	30
HW-ENPG21/29H	HW-ENPG21/29C	PG21	PG29	8	11	39
HW-ENPG29/36H	HW-ENPG29/36C	PG29	PG36	9	13	50
HW-ENPG36/42H	HW-ENPG36/42C	PG36	PG42	10	15	57
HW-ENPG42/48H	HW-ENPG42/480	PG42	G3/8	10	16	64
HW-EN3/8-1/2H	HW-EN3/8-1/2C	G3/8*	G1/2*	6	10.5	24
HW-EN1/2-3/4H	HW-EN1/2-3/4C	G1/2	G3/4'	6.5	10.5	30
HW-EN3/4-1H	HW-EN3/4-1C	G3/4°	G1	7.5	13	40
HW-EN1-1-1/4H	HW-EN1-1-1/4C	G1*	G1-1/4"	8	13	50
