Specifications
■Roted operation current(le): 9-95A;
■Roted operation voltoge(Ue): 220V~690V;
■Rated insulotion voltage: 690V;
■Poles: 3P:
■Instollation: Din raill and screw installation
Operating and Installation Conditions
type | operating and instolliation conditions |
Installaton category | Ⅲ |
Pollution level | 3 |
Certificotion | CE.CB.CCC,TUV |
Protection degree | C7s-09-38 IP20;C7s-40-95 IP10 |
Ambient temperature | limit of temperature-35℃ +70℃. normol temperature-5℃ ~+40℃, The averoge no more than +35 C within 24 hours. If not in normal operating temperature range.please refer to Tnstructions for obnormol environment" |
Alutude | ≤2000m |
Ambient temperature | The maximum temperature of 70 degrees,the air relative humidity not exceed 50%,under lower temperature can allow for higher relative humidity. f the temperature is 20℃.the air relative humidity could up to 90%,Special measures should be token for occasional condensation due to humidity changes |
Instollation position | Inclination between installation surfoce and vertical surface should not exceed±5* |
Shock vibration | Products should be installed and used without significant shake,shock and vibration place |
Specifications
C7s Specifications | |||||||||||||
Type | C7s-09 | C7s-12 | C7s-18 | C7s-25 | C7s-32 | C7s-38 | C7s-40 | C7s-50 | C7s-65 | C7s-80 | C7s-95 | ||
Main circuit choracteristic | |||||||||||||
Poles | 3P | ||||||||||||
Rated insulation voltage(Ui) | V | 690 | |||||||||||
Rated operating voltage(Ue) | V | 380/400.660/690 | |||||||||||
Rated thermal current(ith),AC-1 | 20 | 20 | 32 | 40 | 50 | 50 | 60 | 80 | 80 | 125 | 125 | ||
Rated operation currentle | AC-3.380/400V | A | 9 | 12 | 18 | 25 | 32 | 38 | 40 | 50 | 65 | 80 | 95 |
AC-3,660/690V | A | 6.6 | 8.9 | 12 | 18 | 22 | 22 | 34 | 39 | 42 | 49 | 49 | |
AC-4,380/400V | A | 3.5 | 5 | 7.7 | 8.5 | 12 | 14 | 18.5 | 24 | 28 | 37 | 44 | |
AC-4,660/690V | A | 1.5 | 2 | 3.8 | 4.4 | 7.5 | 8.9 | 9 | 12 | 14 | 17.3 | 21.3 | |
Rated operational power(Pe | AC-3.380/400V | kW | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 18.5 | 22 | 30 | 37 | 45 |
AC-3.660/690V | kW | 5.5 | 7.5 | 10 | 15 | 18.5 | 18.5 | 30 | 33 | 37 | 45 | 45 | |
AC-4,380/400V | kw | 1.5 | 2.2 | 3.3 | 4 | 5.4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | |
AC-4.660/690V | kW | 1.1 | 1.5 | 3 | 3.7 | 5.5 | 6 | 7.5 | 10 | 11 | 15 | 18.5 | |
Mechanical life | 1200 | 1000 | 900 | 650 | |||||||||
Electricol lfe | AC-3 | 10000 times | 110 | 90 | 65 | ||||||||
AC-4 | 22 | 22 | 17 | 11 | |||||||||
Frequency of operation | AC-3 | times/ hour | 1200 | 600 | |||||||||
AC-4 | 300 | 300 | |||||||||||
Connecting copability of main circuit terminal | |||||||||||||
Flexible wire | 1 wire | mm² | 1…4 | 1.5…6 | 2.5…25 | 4…50 | |||||||
No terminal | 2 wire | mm² | 1…4 | 1.5…6 | 2.5…16 | 4…25 | |||||||
Flexible wire | 1 wire | mm | 1…4 | 1…6 | 2.5…25 | 4…50 | |||||||
With terminals | 2 wire | mm2 | 1…2.5 | 1…4 | 2.5…10 | 4…16 | |||||||
Hard wire | 1 wire | mm2 | 1…4 | 1.5.6 | 1.5..10 | 2.5…25 | 4…50 | ||||||
No terminal | 2 wire | mm2 | 1…4 | 1.5… | 2.5…10 | 4…25 | |||||||
Fastening torque | Nm | 1.2 | 1.8 | 5 | 9 | ||||||||
Coil | |||||||||||||
Rated control voltage(Us) | 50Hz | V | 24、36、48、110、127、220/230、240、380/400、415、440 | ||||||||||
50/60Hz | V | 24、36、48、110、127、220/230、240、380/400、415、440 | |||||||||||
Allowed control circuit voltagel(Usl | Operation | V | Installation inclination angle ±22.5*:85%~110%Us;Installation inclination angle±5:70%~120% | ||||||||||
Release | V | Installation inclination angle±22.5*:20%~75%Us;Installation inclination angle±5°:20%~65% | |||||||||||
Power consumption of coil | Actuation | VA | 60 | 70 | 200 | 200 | |||||||
Keep | VA | 6-9.5 | 6-9.5 | 15-20 | 15-20 | ||||||||
Consumption | W | 1-3 | 1-3 | 6-10 | 6-10 | ||||||||
Auxiliary contacts | |||||||||||||
Auxiliary contocts specification | A | 11 | |||||||||||
Rated thermal current (lth) | A | 10 | |||||||||||
Rated operating voltoge (Ue | AC | V | 380 | ||||||||||
DC | V | 220 | |||||||||||
Rated control capacit | AC-15 | VA | 360 | ||||||||||
DC-13 | W | 33 | |||||||||||
Certification | CCC,CE.TUV.CB |
Overall and Mounting
C7s-09~38
C7s-09- -38
TyPe Amax | Amax | Emax | Cmax | a | b | C | d | e | f |
C7s-09.12.18 | 74.5 | 45.5 | 85.5 | 35 | 50/60 | ||||
C7s-25.32.38 | 83 | 56.5 | 97 | 40 | 50/70 | ||||
C7s-40.50.65 | 127.5 | 74.5 | 117 | 105 | 40 | 100/110 | 59 | ||
C7s-80.95 | 127.5 | 85.5 | 125.5 | 105 | 40 | 100/110 | 67 |
