CAS Type Copper-aluminum Terminal

For 35kV and below aluminum, aluminum conductor cable and electrical equipment copper terminal transition connection
Advanced copper-aluminum welding technology, processing of the plate after welding
Equipped with special conductive paste, and optional terminal insulation sleeve
Use special crimping tools, crimping more firmly
Copper >99.9%; Aluminum >99.5%

Availability:



Inquire Add to Basket

Model:
CAS
Brand:
YUANKY
Intercontinental Product:
America

Product Description

Type specification	Conductor section (mm)	Main size (mm)			Bolt diameter Can be customized upon request	Confining die specifications
Type specification	Conductor section (mm)			W	Bolt diameter Can be customized upon request	Confining die specifications
CAS-10	10	4.5	90	20	M6,M8,M10	K 16
CAS-16	16	5.5	90	24	M6,M8,M10,M12	K 16
CAS-25	25	6.5	90	24	M6,M8,M10,M12	K16
CAS-35	35	8.0	90	24	M6,M8,M10,M12	K16
CAS-50	50	9.0	92	24	M8,M10,M12	K20
CAS-70	70	11.0	92	24	M8,M10,M12	K20
CAS-95	95	12.5	92	24	M8,M10,M12	K20
CAS-120	120	13.5	117	30	M8,M10,M12	K25
CAS-150	150	15.5	117	30	M8,M10,M12	K25
CAS-185	185	17.0	117	30	M8,M10,M12	K32
CAS-240	240	19.5	117	30	M8,M10,M12	K32
CAS-185	185	17.0	124	35	M8,M10,M12,M16	K32
CAS-240	240	19.5	124	35	M8,M10,M12,M16	K32
CAS-300	300	23.3	130	35	M8,M10,M12,M16	K 34
CAS-300	300	23.3	160	36	M8,M10,M12,M16	K40
CAS-400	400	26.0	160	36	M8,M10,M12,M16	K40
CAS-500	500	29.0	200	60X60	单眼，双眼，四眼	K47
CAS-630	630	32.5	200	60X60	单眼，双眼，四眼	K47
CAS-800	800	37.5	260	80X80	单眼，双眼，四眼	K60
CAS-1000	1000	42.0	260	80×8(	单眼，双眼，四眼	K60
