Industrial Thermostat Switch Mechanical KTS011

Switching difference : 12.6 °F ± 7°F tolerance (7 K ± 4 K)

Sensor element:  Thermostatic bimetal

Contact mode:  Quick-acting type

Service life:  >100,000 cycles

Maximum operating voltage: 250VAC

Maximum surge current :  AC 16 A lasts 10 seconds

Housing material:  PC

weight: 40g

Installation mode: 35MM DIN rail

Operating/storage temperature: -45 to 80 ° C

Operation/storage humidity：Max. 90%RH (non-condensing)

Class of protection：IP20
