Technical Data
■Ratedcurrent:6A, 10A,16A,20A,25A,32A,40A,50A
■Rated voltage:240V(230V)~
■Rated frequency:50/60Hz
■Number of pole:1P+N
■Module size: 18mm
■Curve type:B&C Curve
■Breaking capacity:6000A
■Rated residual operating current:
10mA,30mA, 100mA,300mA Type A and AC
■Optimum operating temperature:- -25C to 40C
■Terminal Tightening torque:1.2N-m
■Terminal Capacity(top): 16mm2
■Terminal Capaity(bottom): 16mm2
■Electro-mechanical endurance:4000 cycles
■Mounting:35mm DinRail
■I Line and Load reversible:
Suitable Busbar:PIN Busbar
Compliance
■IEC/EN/AS/NZS61009.1:2015
■ESV Compliant
