Photoelectric Switch Infrared Light

Magnetic proximity switches include eddy current proximity switches, capacitive proximity switches, Hall proximity switches, photoelectric proximity switches, pyroelectric proximity switches, TCK magnetic switches and other proximity switches. Because the displacement sensor can be made according to different principles and different methods, and different displacement sensors have different "perception" methods for the object, there are the following common proximity switches: eddy current proximity switches This switch is sometimes called inductive proximity switches. It is the use of conductive objects in close proximity to this can generate an electromagnetic field.

Availability:



Inquire Add to Basket

Brand:
YUANKY
Intercontinental Product:
America

Product Description

NPN	NPN NO	HW3F-DS10C1	HW3F-DS30C1	HW3F-T5C1	HW3F-T5DL	HW3F-R2C1
	NPN NC	HW3F-DS10C2	HW3F-DS30C2	HW3F-T5C2		HW3F-R2C2
	NPN NO+NC	HW3F-DS10C12	HW3F-DS30C12	HW3F-T5C12		HW3F-R2C12
PNP	PNP NO	HW3F-DS10P1	HW3F-DS30P1	HW3F-T5P1		HW3F-R2P1
	PNP NC	HW3F-DS10P2	HW3F-DS30P2	HW3F-T5P2		HW3F-R2P2
	PNP NO+NC	HW3F-DS10P12	HW3F-DS30P12	HW3F-T5P12		HW3F-R2P12
Inspection distance		10cm	30cm	5m	5m	2m
illuminant		Infrared LED
Reaction time		1.5msMax
Standard test substance		12*12cm white paper		Opaque above φ20mm	φ80mm or above opacification
Operating voltage		DC10-30V±10%
Current consumption		25mA	45mAMax(Beam 25mA, receive 20mA)		25mA
Control output		Max 100mA(Max 30VDC), residual voltage; Max. 1V
Ambient illumination		Incandescent lamp: maximum 5000lux, daylight: maximum 20000lux
Operating temperature		25℃ ~+70℃
Ambient humidity		35 to 85%, no condensation
Connection mode		φ3.7×2m/3Cores
Blocking impedance		20MΩmin.500VDC
Insulation voltage		1000VAC for 1 minminute
Waterproof class
Housing material		Plastic case type: PBT/PC, lens: PMMA
