YUANKY HW-MF ABS PVC Waterproof Junction Box

Shell material: ABS transparent door panel: PC terminal block: copper material characteristics;
It features excellent impact resistance, heat resistance, low-temperature resistance, chemical resistance, electrical performance and good surface gloss. Certification: CE, ROHS. Protection grade: IP50. Application: Suitable for indoor and outdoor electrical, communication, fire-fighting equipment and steel smelting.
Petrochemicals, electronics, power, railways, construction sites, mining sites, airports, hotels, ships, large factories, coastal factories, unloading wharf equipment, sewage and wastewater treatment facilities, environmental pollution control facilities, etc.
Installation method: 1. Internal installation: The box is equipped with a rail for the installation of the rail-mounted circuit breaker, as well as a neutral wire bar and a ground wire bar for wiring.
2. External installation: It can be directly embedded into the wall through the installation holes at the bottom of the box body.
Wire inlet and outlet holes: The box body is equipped with reserved holes for threading wires.
