Availability: | |
---|---|
HWSP
YUANKY
America
Characteristics | HWSP-60 | HWSP-70 | HWSP-80 | HWSP-90 | HWSP-100 | HWSP-110 | HWSP-120 | HWSP-130 |
Open-Circuit Voltage(Voc) | 21.8 | 21.4 | 21.8 | 21.8 | 22 | 21.4 | 21.6 | 21.6 |
Optimum Operating Voltage(Vmp) | 17.8 | 17.2 | 17.6 | 17.8 | 18 | 17.2 | 17.4 | 17.6 |
Short-Circuit Current(Isc) | 3.85 | 4.56 | 5.23 | 5.6 | 6.12 | 6.86 | 7.42 | 7.83 |
Optimum Operating Current(Imp) | 3.38 | 4.07 | 4.55 | 5.06 | 5.56 | 6.4 | 6.9 | 7.39 |
Maximum power at STC(Pmax) | 60W | 70W | 80W | 90W | 100W | 110W | 120W | 130W |
Operating Temperature | -40℃to+85℃ | |||||||
Maximum System Voltage | 1000VDC | 1000VDC | 1000VDC | 1000VDC | 1000VDC | 1000VDC | 1000VDC | 1000VDC |
Series Fuse Rating | 11A | 11A | 11A | 15A | 15A | 15A | 15A | 15A |
Power Tolerance | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% |
NO.of Cells | 72 | 36 | 108 | |||||
Dimensions (MM) | 835×540 × 28 | 910×510×28 | 1000×510×28 | 1100×510×28 | 1210×540×28 | 1250 ×808× 35 | 1250 ×808×35 | 1250 × 808 ×35 |
Weight (KG) | 5.5 | 8.2 | 11.8 | |||||
Front Glass | 3.2mm tempered glass | |||||||
Frame | Anodised aluminium alloy | |||||||
Junction Box | PV-Rh701 | PV-RH701 |
Nominal Operating Cell Temperature(NOCT) | 45±2℃ |
Temperature Coefficient of Pmax | -0.48%/℃ |
Temperature Coefficient of Voc | -0.34%/℃ |
Temperature Coefficient of Isc | -0.017%/℃ |
