◆Product material:Location C and Fare made of high-quelitv thickened zjnc alloy,B and E are made of Chemigums,and D is made of galvanized iron
◆Specification fo thread: G,metric,PG
◆Color:Metallic color (silver white)
◆Working temperature:-40℃~+100℃,instantaneously can be+120℃
◆Protection Classification:IP65
◆Property:1.Thickened zinc alloy or chromium plated;nice looking,compact structure and high strength.
2.Flexible design make conduit connection tightly,easy assembly,and strong pull resistance.
3.Water resistant,dust resistant,inactive with salts,acid and alkali resistance,alcohols,oils and greases as well as general
solvent.
Besides the following specifications,the size of pipe fittings can be varied at your discretion as per requirements.
产品型号 Item No | 配套金属软管(公制) Metal Flexible conduit(Metric) | 螺牙厚钢管(水、煤、气管) Theaced Thick steel conduit(waie,gas steam conduits) | 薄钢管(电线管) Thin steel conduit(electric wire conduit) | 包装单位(个/包) Packaging unit | ||
公制 Metric | 外径×壁厚 outer dame'er x wall thickness | 公制 Metric | 外径×壁厚 outer diameler x wall thickness | |||
HW-DKJ-10 | 中10 | #10 | #12 | 12.76×1.60 | 100 | |
HW-DKJ-12 | φ12(13) | #12 | 17.00×2.25 | #15 | 15.87×1.60 | 100 |
HW-DKJ-16 | 中16(15 | #15 | 21.25×2.75 | #20 | 19.05×1.80 | 50 |
HW-DKJ-20 | 中20(19 | #20 | 26.75×2.75 | #25 | 25.40×1.80 | 50 |
HW-DKJ-25 | 中25 | #25 | 33.50×3.25 | #32 | 31.75×1.80 | 50 |
HW-DKJ-32 | 中32 | #32 | 42.25×3.25 | #40 | 38.10×1.80 | 20 |
HW-DKJ-38 | 中38(40) | #40 | 48.00×3.50 | #50 | 50.80×2.00 | 20 |
HW-DKJ-51 | 中51(50) | #50 | 60.00×3.50 | #70 | 53 5U2.50 | 20 |
HW-DKJ-64 | φ64(70 | #70 | 75.50×3.75 | #80 | 76.20×3.20 | 10 |
HW-DKJ-75 | 中75(80) | #80 | 88.50×4.00 | 5 | ||
HW-DKJ-100 | 中10 | #100 | 114.00×4.00 | 5 | ||
HW-DKJ-125 | 中125 | #125 | 140.00×4.50 | 5 | ||
HW-DKJ-150 | 中150 | #150 | 165.00×4.50 | 5 |
