CM SERIES SOLAR CONTROLLER

Availability:
Inquire Add to Basket

  • CM

  • YUANKY

  • America

MODEL CMS1024 CMS1524 CMS2024 CMS2524
Rated Voltage                                                               12V/24VAUTO
Rated Current 10A
 15A 20A 25A
USB Output                                                                   5V.2.1A
Light Control                                                                      YES
Time Control                                                                      YES
DC PORT                                                                  12V/24V
Package                                                                 Color BOX
PCS/CTN                                                                 50pcs/ctn
Size                                                               84*145*38mm
N.W.                                                                     0.2 kg
MODEL CM3024Z CM4024Z
Rated Voltage                                             12V/24V AUTO
Rated Current 30A 40A
Light Control                                                     YES
Time Control                                                     YES
DC PORT                                                  12V/24V
Package                                                Color BOX
PCS/CTN                                                30pcs/ctn
Size                                              93*187*50 mm
N.W.                                                     0.33kg
MODEL CM5024Z CM6024Z CM8024Z CM5048Z CM6048Z CM8048Z
Rated Voltage                    12V/24V AUTO                               48V
Rated Current 50A
 60A 80A 50A 60A 80A
Light Control                                                                      YES
Time Control                                                                      YES
DC PORT                                                                  12V/24V
Package                                                                 Color BOX
PCS/CTN                                                                 24pcs/ctn
Size                                                              131*187*61 mm
N.W.                                                                     0.58 kg
