产品材质： 采用工程尼龙料制造，强度高、重量轻、适合快速移动、结构坚固、不会变形。
◆应用范围： 化工、机械、电力、运输船舶等行业应用。
◆Product material:Engineering polyamide is used in manufactureing.It is impact resistant with high strength and light in weight.It is suitable for quick
◆Application: Used in such fields as chemical industry,machinery,electric power and transportation
规格参数
产品型号 Item No |
内高 hi |
内宽 wi |
外高 ho |
外宽 wo |
节/米 |
接头孔距 D |
弯曲半径 R |
节的组装类型 |
10系列 |
10 |
10 |
14 |
16.5 |
68 |
R28、R38、R48* |
开口 |
|
10 |
15 |
15.5 |
23 |
51 |
||||
10 |
20 |
15.5 |
28 |
51 |
||||
15系列 |
15 |
15 |
20 |
26 |
39 |
R28、R38、R48* |
开口/半封闭 |
|
15 |
20 |
19.5 |
28 |
49 |
||||
15 |
30 |
20 |
38 |
49 |
半封闭 |
|||
18系列 |
18 |
18 |
23.5 |
30 |
30 |
R28、R38、R48* |
开口 |
|
18 |
25 |
24.5 |
37 |
30 |
开口/半封闭 |
|||
18 |
37 |
23.5 |
49.5 |
30 |
||||
18 |
50 |
24 |
63 |
30 |
半封闭 |
|||
20系列 |
20 |
25 |
31 |
41 |
22 |
R55、R75*、R100* |
开口 |
|
20 |
38 |
31 |
54 |
22 |
||||
20 |
50 |
31 |
66 |
22 |
||||
20 |
57 |
31 |
73 |
22 |
||||
20 |
77 |
31 |
93 |
22 |
||||
20 |
103 |
31 |
119 |
22 |
||||
25系列 |
25 |
25 |
36 |
39 |
22 |
R55、R75、R100 R125、R150、R175 R200*、R250 |
开口 |
|
25 |
38 |
36 |
52 |
22 |
||||
25 |
57 |
36 |
71 |
22 |
||||
25 |
77 |
36 |
91 |
22 |
||||
25 |
103 |
36 |
118 |
22 |
||||
25 |
38 |
36 |
52 |
22 |
R55、R75、R100 R125、R150、R175 R200*、R250* |
全封闭 |
||
25 |
57 |
36 |
71 |
22 |
||||
25 |
77 |
36 |
91 |
22 |
产品型号 Item No |
内高 hi |
内宽 wi |
外高 ho |
外宽 Wo |
节/米 |
接头孔距 D |
弯曲半径 R |
节的组装类型 |
30系列 |
30 |
25 |
45 |
43 |
21 |
R55*、R75、R100* R125*、R150* |
开口 |
|
30 |
38 |
45 |
56 |
21 |
||||
30 |
50 |
45 |
68 |
21 |
||||
30 |
57 |
45 |
75 |
21 |
||||
30 |
77 |
45 |
95 |
21 |
||||
30 |
103 |
45 |
121 |
21 |
||||
35系列 |
35 |
50 |
56 |
68 |
17 |
R75、R100 R125*、R150* R200* |
开口 |
|
35 |
75 |
56 |
94.5 |
17 |
||||
35 |
100 |
56 |
119 |
17 |
||||
35 |
125 |
56 |
144 |
17 |
||||
35 |
150 |
56 |
169 |
17 |
||||
35 |
175 |
56 |
9 |
17 |
||||
35 |
200 |
56 |
219 |
17 |
||||
35 |
225 |
56 |
244 |
17 |
||||
35 |
50 |
56 |
68 |
17 |
D=wi+(2x7.5) |
R75、R100 R125*、R150* R200* |
全封闭 |
|
35 |
75 |
56 |
94.5 |
17 |
||||
35 |
100 |
56 |
117 |
17 |
||||
45系列 |
45 |
50 |
56 |
79 |
14 |
D=wi+(2x8) |
R100、R125 R150、R175* R200*、R225* R250* |
开口 |
45 |
75 |
56 |
104 |
14 |
||||
45 |
100 |
56 |
129 |
14 |
||||
45 |
125 |
56 |
154 |
14 |
||||
45 |
150 |
56 |
179 |
14 |
||||
45 |
175 |
56 |
204 |
14 |
||||
45 |
200 |
56 |
229 |
14 |
||||
45 |
225 |
56 |
254 |
14 |
||||
45 |
50 |
56 |
79 |
14 |
D=wi+(2x8) |
R100、R125、R150 R175*、R200* R225*、R250* |
全封闭 |
|
45 |
75 |
56 |
104 |
14 |
||||
45 |
100 |
56 |
129 |
14 |
||||
55系列 |
55 |
50 |
77 |
74 |
14 |
R100、R125 R150、R175° R200*、R225* |
开口 |
|
55 |
75 |
77 |
99 |
14 |
||||
55 |
100 |
77 |
124 |
14 |
||||
55 |
125 |
77 |
149 |
14 |
||||
55 |
150 |
77 |
174 |
14 |
||||
55 |
175 |
77 |
199 |
14 |
||||
55 |
200 |
77 |
224 |
14 |
||||
55 |
225 |
77 |
249 |
14 |
||||
60系列 |
60 |
100 |
88 |
138 |
10 |
D=wi+(2x9) |
R150、R175* R200*、R250* R300* |
开口 |
60 |
125 |
88 |
163 |
10 |
||||
60 |
150 |
88 |
188 |
10 |
||||
60 |
200 |
88 |
238 |
10 |
