| Specification |
DTSY5558 |
||
| Accuracy |
Active |
Class1.0 |
|
| Reactive |
Optional |
||
| Voltage |
Rated |
3x57.7/100V,3x220/380V 3x230/400V,3x240/415V |
|
| Range |
0.9Un~1.1Un |
||
| Limit |
0.8Un-1.2Un |
||
| Frequency |
50/60Hz |
||
| Current |
Range |
3x1.5(6), 3x 5(30), 3x 10(50),3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A |
|
| Starting Current |
0.4%lb |
||
| Constant |
Active |
400 imp/kWh ,800imp/kWh, 1600imp/kWh |
|
| Reactive |
/ |
||
| Display |
Type |
LCD |
|
| Digit |
6+2 |
||
Power Consumption |
Voltage Circuit |
≤0.8W,10VA |
|
| Current Circuit |
≤4VA |
||
| Communication |
Interface |
Optical/Infrared/RS485 (Optional) |
|
| Protocol |
MODBUS,DLT/645,IEC1107 |
||
| Temperature |
Working Temperature |
-45°C~+55°℃ |
|
| Storage Temperature |
-40°C-+70°℃ |
||
| Humidity |
≤90% |
||
| Protection |
IP54 |
||
