BHB Bolt On Circuit Breakers circuit breaker

Availability:
Inquire Add to Basket

  • America

Description

For protection against overlood and short circuits in the electrical distribution system.Use in domestic ,commercial and light industrial installations.

Conform to lEC 60898,BS 3871.

Degree of protection: IP 20

Specification

Product Number Ampere rating Rated Voltage(Vac) #of poles
BHB106 6 120/240 1
BHB110 10 120/240 1
BHB116 16 120/240 1
BHB120 20 120/240 1
BHB125 25 120/240 1
BHB130 30 120/240 1
BHB140 40 120/240 1
BHB150 50 120/240 1
BHB160 60 120/240 1
BHB216 16 120/240 2
BHB220 20 120/240 2
BHB225 25 120/240 2
BHB230 30 120/240 2
BHB240 40 120/240 2
BHB250 50 120/240 2
BHB260 60 120/240 2
BHB330 30 120/415 3
BHB340 40 120/415 3
BHB350 50 240/415 3
BHB360 60 240/415 3
BHB375 75 240/415 3
BHB3100 100 240/415 3

图4
