GTL
YUANKY
America
Type specification |
Conductor section (mm²) Aluminum/copper wire |
Main size (mm) |
||
| d | d1 |
L | ||
GTL-1610 |
AL16/CU10 |
5.6 |
4.5 |
66.5 |
GTL-2510 |
AL25/CU10 |
6.4 |
4.5 |
66.5 |
GTL-2516 |
AL25/CU16 |
6.4 |
5.5 |
72.5 |
GTL-3516 |
AL35/CU16 |
8.5 |
5.5 |
72.5 |
GTL-3525 |
AL35/CU25 |
8.5 |
7.0 |
72.5 |
GTL-5025 |
AL50/CU25 |
9 |
7.0 |
75 |
GTL-5035 |
AL50/CU35 |
9 |
8.2 |
75 |
CTL-7035 |
AL70/CU35 |
10.9 |
8.2 |
75 |
CTL-7050 |
AL70/CU50 |
10.9 |
10 |
81 |
CTL-9550 |
AL95/CU50 |
12.4 |
10 |
81 |
GTL-9570 |
AL95/CU70 |
12.4 |
11.5 |
83 |
GTL-12070 |
AL120/CU70 |
13.7 |
11.5 |
99 |
GTL-12095 |
AL120/CU95 |
13.7 |
13.5 |
107 |
GTL-15095 |
AL150/CU95 |
15.5 |
13.5 |
107 |
GTL-150120 |
AL150/CU120 |
15.5 |
15.5 |
107 |
GTL-185120 |
AL185/CU120 |
17 |
15.5 |
107 |
GTL-185150 |
AL185/CU150 |
17 |
17 |
112 |
GTL-240150 |
AL240/CU150 |
19.5 |
17 |
112 |
GTL-240185 |
AL240/CU185 |
19.5 |
19 |
115 |
GTL-300185 |
AL300/CU185 |
23.2 |
19 |
152.5 |
GTL-300240 |
AL300/CU240 |
23.2 |
21.5 |
153.5 |
GTL-400240 |
AL400/CU240 |
26 |
21.5 |
153.5 |
GTL-400300 |
AL400/CU300 |
26 |
24.5 |
159.5 |
