HW85
YUANKY
America
| MODEL | Norminal Diameter | Permanent Flow Rate | Transitional Flow Rate |
MMinimm Flow Rate | Meter Sensor Connection Size | Pipe sensor connection size | Motor Length | |||
| DN(mm) | Q 3(m3/h) | Q 2(m3/h) | Q 1(m3/h) | Thread Length | Connection Thread | Connection Length | Thread length | Thread Specification | (mm) | |
| DN15 | 15 | 2.5 |
0.010 | 0.006 |
12 |
G3/4B |
43 | 15 | R1/2 | 165 |
| DN20 | 20 | 4.0 |
0.016 |
0.010 |
12 |
G1B | 50 | 16 | R3/4 | 195 |
| DN25 | 25 | 6.3 | 0.025 | 0.016 |
12 |
G11/4B | 58 | 18 | R1 |
225 |
| DN32 | 32 | 10 |
0.040 | 0.025 |
13 | G11/2B |
58 |
20 | R11/4 |
180 |
| DN40 |
40 | 16 | 0.064 | 0.040 |
14 | G2B | 59 | 22 | R11/2 |
200 |
| DN50 | 50 | 25 | 0.160 |
0.1 | 15 | G21/2B |
60 | 24 | R3/4 |
200 |
| Param-eters | Diameter Range: DN15 Pressure Class: MAP16 Temperature Range: (°C) 0-30 Pressure Loss Class: △p25 Protection Class: IP68 Pipe Material : Copper Working Temperature: (°C)-20-55 Dynamic Range : 125-400 Ambient Class: Class O EMC Level : E1 Installation Mode : H/V Flow Section Sensitivity Level : U5/D3 |
|||||||||
