HWSP Series Mono-crystalline solar panel Poly-crystalline solar panel

·50Watt Maximum power
•High conversion efficiency based on leading innovative photovoltaic technologiesH
• High stability with guaranteed+/-3%power output tolerance,ensuring return on investment
• Beautiful appearance
• Withstands high wind-pressure and snow load
• Easy to install
Availability:
  • HWSP

  • YUANKY

  • America

Characteristics HWSP-5 HWSP-10 HWSP-15 HWSP-20 HWSP-30 HWSP-40 HWSP-45 HWSP-50
Open-Circuit Voltage(Voc) 21
21.2 21.4 21.4 21.4 21.6 21.6 21.6
Optimum Operating Voltage(Vmp) 16.8 17 17.2 17.2 17.2 17.4 17.66 17.6
Short-Circuit Current(Isc) 0.38 0.68 1.06 1.4 1.96 2.72 2.89 3.16
Optimum Operating Current(Imp) 0.3 0.59 0.88 1.17 1.75 2.3 2.56 2.85
Maximum power at STC(Pmax) 5W 10W 15W 20W 30W 40W 45W 50W
Operating Temperature                                                                  -40℃to+85℃
Maximum System Voltage 1000VDC 1000VDC 1000VDC 1000VDC 1000VDC 1000VDC 1000VDC 1000VDC
Series Fuse Rating 11A 11A 11A 11A 11A 11A 11A 11A
Power Tolerance ±3% ±3% ±3% ±3% ±3% ±3% ±3% ±3%
NO.of Cells                                                                     36 72
Dimensions (MM) 285×185×20 350×285×23 440×290×23 639×294×23 570×414×23 535×510×23 535×510x23 685×510×25
Weight (KG) 0.7 1.4 2.1 2.4 2.5 5.2 5.2 5.5
Front Glass                                                                                        3.2mm tempered glass
Frame                                                                                      Anodised aluminium alloy
Junction Box                                                             PV box2                PV-RH701
Nominal Operating Cell Temperature(NOCT) 45±2℃
Temperature Coefficient of Pmax -0.48%/℃
Temperature Coefficient of Voc -0.34%/℃
Temperature Coefficient of Isc -0.017%/℃
