Standard capacitive access switch Professional capacitive access switch for livestock industry

Magnetic proximity switches include eddy current proximity switches, capacitive proximity switches, Hall proximity switches, photoelectric proximity switches, pyroelectric proximity switches, TCK magnetic switches and other proximity switches. Because the displacement sensor can be made according to different principles and different methods, and different displacement sensors have different "perception" methods of the object, there are the following common proximity switches: eddy current proximity switches This switch is sometimes called inductive proximity switches. It is the use of conductive objects in close proximity to this can generate an electromagnetic field.
Availability:
  • HW0

  • YUANKY

  • America

Technical parameter
Detection distance

1.5mm、 2mm

Switching frequency 200HZ
Return gap Within 10% of the detection distance Full-load current

≤150mA、≤200mA

Rated distance

70% of the detection distance

Temperature drift control Within the range of -25-70° C, within 10% of the detection distance at 25 ° C
Standard test substance 8*8 1mm iron, 12*12 1mm iron Output indication Green LED,360° view
Supply voltage

10~30V

Protection circuit Power reverse protection, output reverse protection, load break protection, overload protection, surge protection
Saturation step-down ≤1.5V Ambient temperature -25° C ~70° C (unfrozen)
Static working current <10mA Storage temperature -30 ° C ~80° C (unfrozen)
repeatability repeatability
NPN output

HW0-M05N1

HW0-M08N1

HW0-M12N1

HW0-M22N1

HW0-M30N1

HW0-M05N2

HW0-MO8N2

HW0-M12N2

HW0-M22N2

HW0-M30N2

PNP output

HW0-M05P1

HW0-M08P1 HW0-M12P1 HW0-M22P1 HW0-M30P1
HW0-M05P2 HW0-M08P2 HW0-M12P2 HW0-M22P2 HW0-M30P2


Minimum detection object φ0.4mm*1 φ0.5mm*1 φ0.6mm*1 φ1.0mm*1 φ1.5mm*1
Detecting object Magnetic metal (non-magnetic metal minimum detection object volume increase)
Response frequency 100HZ
Supply voltage 10~30VDC
Leakage current Below 0.8mA
Switching capacity 3-100mA

Control output

Less than 3V (load current 100mA, wire length 2m)
Residual voltage
Pilot lamp Action light (red)
Action pattern Type 1; Normally open N.O.; Type 2: Normally closed N.C
Protection loop Surge protection circuit, short circuit protection, polarity reverse protection
Ambient temperature When acting, when saving; Each 30~95%RH(no condensation)
Protective mechanism P67
Effect of temperature Temperature range -25~70℃, every change of 20℃, the size of the detected substance changes within ±10%
Voltage effect When the rated power supply voltage range fluctuates within ±15%, the size of the detected object changes within ±1%
Insulation impedance More than 50 megohm (DC500 megohm meter) between the charging part and the housing
Withstand voltage AC1000V50/60Hz1min between charging part and housing
Vibration resistance 10 to 55Hz, composite amplitude 1.5mm,X, Y, Z axis direction 2 hours each
Shock resistance 1500m/s²X/Y/Z 5 times in each direction
Connection mode None: lead out type (standard 2m can be extended)
Shell material 0.3-22 Aperture: PC25-100 Aperture: POM Inner ring Material: POM
Inner hole size (D) φ6.5mm φ8.5mm φ12.5mm φ22.5mm φ30.5mm
