HWS Series Contactor AC.contactor

Availability:
Inquire Add to Basket

  • America

Type HWS-T35 HWS-T50 HWS-T65 HWS-T80 HWS-T100
KWHP(AC)3
Rated powerlAC-3]
IEC60947-4		 220V 7.5 11
 15 19 22
380V 15 22 30 37 45
Rated operated
currentlAC-3
GB14048.4		 220V 35 50 65 80 100
380V 32 48 65 80 93
Conventional thermol currentiAl 60 80 100 120 150
Rated insulated voltoge(V) 690
Aualiary
contact
(AC-15)
Standard 2NO+2NC
Rated
currentiA		 120V 6
220V 3
Electrical life 200 1000
Mechonical life 1000 500
Overall dimension 75×89x91 86x106x106 100x124x127
Instollation dimension 65x60 70x75 80x110
Control coil
rated voltage(VI
50/60Hz		 AC24V 24
AC48V 48-50
AC100V 100~127
AC200V 200~240
AC300V 260-300
AC400V 380-400
AC500V 460-550
