YUANKY AC contactor C7S series A.C. contactor 9-95A contactors

 Product Overview C7S series AC Contactor with novel appearance and compact structure is suitablefor using starting & controlling the AC motor frequently, switching on and off the circuit at a long distance. It is used in combination with thermal relay to compose a magnetic motor starter.


Inquire Add to Basket

Standard: IEC60947-1, IEC60947-4-1.

Specifications

Rated operation current(le):9-95A;

Rated operation voltage(Ue):220V~690V;

Rated insulation voltage:690V;

Poles:3P;

Installation: Din rail and screw installation

Operating and Installation Conditions

Type Operating and Installation Conditions
Installation category Ⅲ
Pollution level   3
Certification CE，CB，CCC，TUV
Protection degree C7S-09~38:IP20；C7S-40~95:IP10
Ambient temperature limit of temperature:-35℃~+70℃，normal temperature:-5℃~+40℃， The average no more than +35C within 24 hours.If not in normal operating temperature range，please refer to”Instructions for abnormal environment”
Altitude ≤2000m
Ambient temperature The maximum temperature of 70 degrees，the air relative humidity not exceed 50%，under lower  temperature can allow for higher relative humidity.If the temperature is 20℃，the air relative humidity could up to 90%，Special measures should be taken for occasional condensation due to humidity changes.
Installation position Inclination between installation surface and vertical surface should not exceed±5°
Shock vibration  Products should be installed and used without signicant shake，shockand wbration place.

C7S series AC contactor 9-95A contactors 1 C7S series AC contactor 9-95A contactors 2 C7S series AC contactor 9-95A contactors 3 C7S series AC contactor 9-95A contactors 4 C7S series AC contactor 9-95A contactors 5 C7S series AC contactor 9-95A contactors 6 C7S series AC contactor 9-95A contactors 7 C7S series AC contactor 9-95A contactors 8 C7S series AC contactor 9-95A contactors 9 C7S series AC contactor 9-95A contactors 10 C7S series AC contactor 9-95A contactors 11 C7S series AC contactor 9-95A contactors 12
