Feature
Up to 10 Functions (from 0.1s to 10days)
Contact Configuration
Universal Power Supply
2 LED Status Indicators
Only 17.5mm Wide
DIN Rail Mountable
RoHS Compliant
Availability: | |
---|---|
America
Benefits
5 Timing Functions Controlled via Supply Voltage
4 Timing Functions Controlled via Trigger Input
1 Timing Function of Memory Latching Relay
Meets Most Timing Requirements
SPDT/DPDT
12 to 240VAC/VDC
Indicates Coil Status at a glance
Ideal for Tight Spaces
Easy Installation/No Tools
Environmentally Friend
Function | Operation | Timing Chart |
A On Delay Power On | When the input voltage U is applied, timing delay t begins. Relay contacts R change state after time delay is complete. Contacts R return to their shelf state when input voltage U is removed. Trigger switch is not used in this function. |
|
B Repeat Cycle Starting Off | When input voltage U is applied, time delay t begins. When time delay t is complete, relay contacts R change state for time delay t. This cycle will repeat until input voltage U is removed. Trigger switch is not used in this function. |
|
C Interval Power On | When input voltage U is applied, relay contacts R change state . Immediately and timing cycle begins. When time delay is complete, contacts return to shelf state. When input voltage U is removed, contacts will also return to their state. Trigger switch is not used in this function. | |
D Off Delay S Break | Input voltage U must be applied continuously. When trigger S is closed, relay contacts R change state. When trigger S is opened, delay t begins. When delay t is complete, contacts R return to their shelf state. If trigger S is closed before time delay t is complete, then time is reset. When trigger S is opened, the delay begins again, and relay contacts remain in their energized state, if input voltage U is removed, relay contacts R return to their shelf state. |
|
E Retriggerable One Shot | Upon application of input voltage U, the relay is ready to accept trigger signal S. upon application of the trigger signal S, the relay contacts R transfer and the preset time t begins. At the end of the preset time t, the relay contacts R return to their normal condition unless the trigger signal S is opened and closed prior to time out t (before preset time elapses). Continuous cycling of the trigger signal S at a rate faster than the preset time will cause the relay contacts R to remain closed. If input voltage U is removed, relay contacts R return to their shelf state. |
|
F Repeat Cycle Starting On | When input voltage U is applied, relay contacts R change state immediately and time delay t begins. When time delay t is complete, contacts return to their shelf state for time delay t. This cycle will repeat until input voltage U is removed. Trigger switch is not used in this function. |
|
G Pulse Generator | Upon application of input voltage U ,a single output pulse of 0.5 seconds is delivered to relay offer time delay t. Power must be removed and reapplied to repeat pulse. Trigger switch S is not used in this function. |
|
H One Shot | Upon application of input voltage U, the relay is ready to accept trigger signal S. Upon application of the trigger signal S, the relay contacts R trasher and the preset time t begins. During time-out, the trigger signal S is ignored. The relay resets by applying the trigger signal S when the relay is not energized. |
|
I On/Off Delay S Make/Break | Input voltage U must be applied continuously. When trigger S is closed, time delay t begins. When time delay t is complete, relay contacts R change state and remain transferred untill trigger S is opened. If input voltage U is removed, relay contacts R return to their shelf state. |
|
J Memory Latch S Make | Input voltage U must be applied continuously. Output changes state with every trigger S closure. If input voltage U is removed, relay contacts R return to their shelf sate. |
Output Characteristics | Timing Characteristics | ||
Number and type of contacts | SPDT or DPPT | Functions Available | 10 |
Contact Material | Silver Alloy | Time Scales | 10 |
Current Rating | 15@240VAC, 24VDC | Time Ranges | 0.1 sec to 10 days |
Switching Voltage | 240V 50/60Hz | Tolerance(Mechanical Setting) | 5% |
24VDC | Repeatability(Constant Voltage and Temperature) | 0.2% | |
1/2HP@120V 50/60Hz | Reset Time(Maximum) | 150ms | |
1HP@240V 50/60Hz | Trigger Pulse Length(Minimum) | 50ms | |
B300 Pilot Duty | |||
Minimum Switching Requirement | 100mA | ||
Indication | Red LED |
Input Characteristics | Performance Characteristics | |||
Voltage Range | 12 to 240V 50/60Hz/VDC | Electrical Life(Operations@Rated Current) | 100,000 Cycles(Resistive) | |
Operating Range(% of Nominal) | 85% to 110% | Mechanical Life(Unpowered) | 10,000,000 Cycles | |
Maximum Consumption | 3VA(AC) | Dielectric Strength | Input to Contacts | 2500VAC |
1.7W(DC) | Between Open Contacts | 1000VAC | ||
Indication | Green LED | Terminal Wire Capacity | 14AWG(2.1mm2) | |
Terminal Torque(Maximum) | 7.1 ibf in(0.8Nm) |
Environment | ||
Product Certifications | CE, RoHS | |
Ambient Air TemperatureAround the device | Storage | -30 to +70(-22 to +158F) |
Operation | -20 to +55(-4 to +131F) | |
Degree of Protection | IP20 | |
Weight | 65Grams(2.3 oz) |
Relay Contact 15A | Load | ||||||||
|
|
| AC1 | AC3 | AC15 | DC1(24/110/220V) | |||
AgNi | 1000W | 4000VA | 0.9kW | 750V | 15A/0.5A/0.35A |
