◆Material:Brass with nickel plated
◆Application:An enlarger is used if the dimensions of existing tapped holes are
too large for a given gland.It provides a means of connection
between cable entry devices and equipment having dissmilar
threads.
◆Accessories:Locknut,Sealing Washer
六角系列 Hexagon |
圆形系列 Circle |
外螺纹(D1) Outer Thread |
内螺纹(D2) Inner Thread |
螺纹长度(GL) Thread Length |
高度(H) Height |
扳手径(D) Spanner Size |
HW-REM16/12H |
HW-REM16/12C |
M16×1.5 |
M12×1.5 |
6 |
9 |
18 |
HW-REM20/16H |
HW-REM20/16C |
M20×1.5 |
M16×1.5 |
6.5 |
9.5 |
22 |
HW-REM25/20H |
HW-REM25/20C |
M25×1.5 |
M20×1.5 |
7.5 |
10.5 |
30 |
HW-REM32/25H |
HW-REM32/25C |
M32×1.5 |
M25×1.5 |
8 |
11.5 |
39 |
HW-REM40/32H |
HW-REM40/32C |
M40×1.5 |
M32×1.5 |
9 |
12.5 |
43 |
HW-REM50/40H |
HW-REM50/40C |
M50×1.5 |
M40×1.5 |
10 |
14 |
57 |
HW-REM63/50H |
HW-REM63/50C |
M63×1.5 |
M50×1.5 |
10 |
14 |
65 |
HW-REPG9/7H |
HW-REPG9/7C |
PG9 |
PG7 |
6 |
9 |
18 |
HW-REPG11/9H |
HW-REPG11/9C |
PG11 |
PG9 |
6.5 |
9.5 |
20 |
HW-REPG13.5/11H |
HW-REPG13.5/110 |
PG13.5 |
PG11 |
6.5 |
9.5 |
22 |
HW-REPG16/13.5H |
HW-REPG16/13.5C |
PG16 |
PG13.5 |
6.5 |
9.5 |
24 |
HW-REPG21/16H |
HW-REPG21/16C |
PG21 |
PG16 |
7.5 |
10.5 |
30 |
HW-REPG29/21H |
HW-REPG29/210 |
PG29 |
PG21 |
8 |
11.5 |
39 |
HW-REPG36/29H |
HW-REPG36/29C |
PG36 |
PG29 |
9 |
12.5 |
50 |
HW-REPG42/36H |
HW-REPG42/36C |
PG42 |
PG36 |
10 |
14 |
57 |
HW-REPG48/42H |
HW-REPG48/42C |
PG48 |
PG42 |
10 |
14 |
64 |
HW-RE3/4-1/2BH |
HW-RE3/4-1/2BC |
G3/4" |
G1/2 |
7.5 |
10.5 |
30 |
HW-RE1-3/4H |
HW-RE1-3/4C |
G1' |
G3/4° |
7.5 |
10.5 |
40 |
HW-RE1-1/4-1H |
HW-RE1-1/4-10 |
G1-1/4" |
G1° |
8 |
11.5 |
50 |
