Standard Proximity Switch

Magnetic proximity switches include eddy current proximity switches, capacitive proximity switches, Hall proximity switches, photoelectric proximity switches, pyroelectric proximity switches, TCK magnetic switches and other proximity switches.
Because displacement sensors can be made according to different principles and different methods, and different displacement sensors have different "perception" methods for objects, there are the following common proximity switches: vortex
Flow close switch
This switch is sometimes called inductive proximity switch. It is the use of conductive objects in close proximity to this can generate an electromagnetic field.

Availability:



Inquire Add to Basket

Model:
HWJ8
Brand:
YUANKY
Intercontinental Product:
America

Product Description

Technical parameter
Output indication	Red LED	Impact resistance	500m/s(about 50G) 3 times in X,Y, and Z directions
Ambient temperature	-25℃~70℃(non freezing state)	Vibration resistance	10~55HZ(cycle 1 minute) Amplitude 1mmX,Y,Z direction for 2 hours
Storage temperature	-30℃~80℃(non freezing state)	Class of protection	IP67
Ambient humidity	30%~95%(no condensation)	Housing material	Nickel plated brass
Insulation impedance	Above 50MΩ (500DC as base)	Connection mode	PVC cable
Withstand voltage	1500V/AC 50/60HZ, one minute

Argument
Detection distance (S)	1mm	2mm	1mm	2mm
Return gap (H)	Within 10% of the detection distance
Rated distance (S)	70% of the detection distance
Standard test substance	8*81mm iron		12*121mm iron
Supply voltage	10~30V
Saturation step-down	≤1.5V
Static working current	<10mA
repeatability	<3%
Switching frequency	1000HZ		1000HZ
Temperature drift control	Within the range of -25~70 ° C, within 10% of the detection distance at 25 ° C
Protection circuit	Power reverse protection, output reverse protection, load break protection, overload protection, surge protection
