CDTL Series Copper Aluminum Terminal

For 35kV and below aluminum, aluminum conductor cable and electrical equipment copper terminal transition connection
Flat screw hole design, suitable for terminal block connection
Professional copper-head manufacturing technology, advanced copper-aluminum welding technology
Equipped with special conductive paste, and optional terminal insulation sleeve
Copper ≥99.9% : Aluminum >99.5%
Availability:
Inquire Add to Basket

  • CDTL

  • YUANKY

  • America

Type specification

Conductor section (mm)

Main size (mm)

Bolt diameter

(Can be customized)

d

 L

W

CDTL-10

10

4.5

45

]4.4

M6,M8

CDTL-16

16

5.5

45

14.4

M6,M8

CDTL-25

25

7.0

45

14.4

M6,M8

CDTL-35

35

8.0

45

14.4

M6,M8

CDTL-50

50

9.5

54

16.7

M8,M10

CDTL-70

70

11.0

54

16.7

M8,M10

CDTL-95

95

12.5

60

17.5

M8,M10

CDTL-120

120

13.7

60

17.5

M8,M10,M12


aluminum terminal copper aluminum terminal
