Type |
Rated voltage (kV) |
MCOV (kV) |
Residual voltage(KV) |
方波冲击电流耐受 2000ms square wave impulse current withstand |
大电流耐受 4/10MS high current impulse (kV) |
||
陡坡冲击电流 Steep impulse current |
操作冲击电流 switching curren impulse |
8/20ms标准雷电冲击 t Lightning current impulse |
|||||
HY5W-3 |
3 |
2.55 |
9.5 |
7.7 |
9 |
100 |
65 |
HY5W-6 |
6 |
5.1 |
19.5 |
15.4 |
18 |
100 |
65 |
HY5W-9 |
9 |
7.65 |
28.5 |
23.1 |
27 |
100/200 |
65 |
HY5W-10 |
10 |
8.4 |
36 |
30 |
23 |
150/200 |
65 |
HY5W-11 |
11 |
9.4 |
40 |
33 |
30 |
150/200 |
65 |
HY5W-12 |
12 |
10.2 |
38.0 |
30.8 |
36 |
100/200 |
65 |
HY5W-15 |
15 |
12.7 |
47.5 |
38.5 |
45 |
100/200 |
65 |
HY5W-18 |
18 |
15.3 |
57.0 |
46.2 |
54 |
100/200 |
65 |
HY5W-21 |
21 |
17.0 |
66.5 |
53.9 |
63 |
100/200 |
65 |
HY5W-24 |
24 |
19.2 |
76.0 |
61.6 |
72 |
100/200 |
65 |
HY5W-27 |
27 |
21.9 |
85.5 |
69.3 |
81 |
100/200 |
65 |
HY5W-30 |
30 |
24.2 |
95.0 |
76.5 |
90 |
100/200 |
65 |
HY5W-33 |
33 |
26.8 |
104.5 |
84.7 |
99 |
100/400 |
65 |
HY5W-36 |
36 |
29 |
114.0 |
92.4 |
108 |
100/400 |
65 |
HY5W-42 |
42 |
34.1 |
132.3 |
100.1 |
126 |
100/400 |
65 |
型号 Type |
额定电压 Rated voltage (kV) |
最大持续 运行电压 MCOV (kV) |
残压Residual voltage(KV) |
方波冲击电流耐受 2000ms square wave impulse current withstand |
大电流耐受 4/10MS high current impulse (kV) |
||
陡坡冲击电流 Steep current impulse |
操作冲击电流 switching current impulse |
8/20ms标准雷电冲击 Lightning current impulse |
|||||
HY10W-3 |
3 |
2.55 |
9.5 |
7.7 |
9 |
100 |
100 |
HY10W-6 |
6 |
5.1 |
19.5 |
15.4 |
18 |
100 |
100 |
HY10W-9 |
9 |
7.65 |
28.5 |
23.1 |
27 |
100 |
100 |
HY10W-10 |
10 |
8.4 |
36 |
30 |
23 |
250 |
150 |
HY10W-11 |
11 |
9.4 |
40 |
33 |
30 |
250 |
150 |
HY10W-12 |
12 |
10.2 |
38.0 |
30.8 |
36 |
200 |
100 |
HY10W-15 |
15 |
12.7 |
47.5 |
38.5 |
45 |
200 |
100 |
HY10W-18 |
18 |
15.3 |
57.0 |
46.2 |
54 |
200 |
100 |
HY10W-21 |
21 |
17.0 |
66.5 |
53.9 |
63 |
200 |
100 |
HY10W-24 |
24 |
19.2 |
76.0 |
61.6 |
72 |
200 |
100 |
HY10W-27 |
27 |
21.9 |
85.5 |
69.3 |
81 |
200 |
100 |
HY10W-30 |
30 |
24.2 |
95.0 |
76.5 |
90 |
200 |
100 |
HY10W-33 |
33 |
26.8 |
104.5 |
84.7 |
99 |
400 |
100 |
HY10W-36 |
36 |
29 |
114.0 |
92.4 |
108 |
400 |
100 |
HY10W-42 |
42 |
34.1 |
132.3 |
100.1 |
126 |
400 |
100 |
HY10W-48 |
48 |
39 |
152.0 |
126.0 |
150 |
400 |
100 |
HY10W-54 |
54 |
43 |
171.0 |
139.0 |
162 |
600 |
100 |
HY10W-60 |
60 |
48 |
208.0 |
160.0 |
180 |
600 |
100 |
HY10W-66 |
66 |
52.8 |
230.0 |
172.0 |
198 |
600 |
100 |
