HQ MCB Miniature Circuit Breaker HQ115 miniature dc circuit breaker

Availability:
Inquire Add to Basket

  • America

Description

For protection against overload and short circuits in the electrical distribution system.Use in domestic.commercial and light industrial installations.

Conform to lEC 60898,BS 3871-Pt1

Body material:Bakelite

Rated Current:5-100A

Rated voltage: 120 120/240,240/440V ACBreaking Capacity:6KA

Frequency:50/60HzDegree of protection:IP20


Specification

Product Number Ampere rating Rated Voltage(Vac) #of poles
HQ115 15 120/240 1
HQ120 20 120/240 1
HQ130 30 120/240 1
HQ140 40 120/240 1
HQ150 50 120/240 1
HQ160 60 120/240 1
HQ175 75 120/240 1
HQ1100 100 120/240 1
HQ215 15 120/240 2
HQ220 20 120/240 2
HQ230 30 120/240 2
HQ240 40 120/240 2
HQ250 50 120/240 2
HQ260 60 120/240 2
HQ275 75 120/240 2
HQ2100 100 120/240 2
HO315 15 240 3
HQ320 20 240 3
HQ330 30 240 3
HQ340 40 240 3
HQ350 50 240 3
HQ360 60 240 3
HQ375 75 240 3
HQ3100 100 240 3
