HW-53F2Z/HW-53F2Z-P,HW-53F3Z/HW-53F3Z-P General Purpose Relay

  • It can choose the flange mounted type
  • The products with the inching test button which Self-locking
  • It can match the socket for HW53S-E
Availability:
Inquire Add to Basket

  • America

Type and meaning

n1

1、Enterprise Code: Haohui Electronics

2、Serial Number

3、Number of contact groups: two,three

4、H-normally open contact Contact Form: z-conversion type D-normally closed contact

5、mounted type: F:flange mounted type P:PCB mounted type No Letters: plug-in moudted

6、operating state:L:LED indicate No Letters:no indicate

7、auxiliary, function : T-Self-locking G-mechanical indicate D/CR-Inhibitory protection

8、Coil Voltage:DCis for direct voltage AC is for alternating voltage

External dimensions (mm)

n2

Wiring diagram

n3


Product performance


Model HW-53F
Dimension(mm) 38x36x56.5
Contact Form 3Z、3H、3D、2Z、2H、2D
Contact Materia SilverAlloy
Resistance Performance Of ContactorCapacity 25A/28VDC、25A/240VAC
Coil Power AC(VA) 2.5
DC(W) 1.8
Coil Voltage AC(V） 6～380
DC(V) 6~220
Pick-up Voltage DC:≤75%、AC:≤80%
Dropout Voltage DC:≥10%、AC;≥30%
Max Voltage 110%
Contact Resistance(mΩ) ≤100mΩ

Dielectric Strength		 Between OpenContacts 1500VAC
Contacs Pieces 1500VAC
BetweenCoil&Contacts 2500VAC
Insulation Resistance (MΩ)at 500VDC ≥100MΩ
Service Life Electrical 5×104
Mechanical 5×105
Ambient Temperature(℃) -25℃~+55℃
Terminal Type Insert Type
Protection Type Close Type
Product Weight(g) 2C:773C:81

Product mix

n4
