YUANKY 9mm 1 pole wifi Micro Circuit Breaker mcb Miniature Circuit Breakers Featured Image
  • YUANKY 9mm 1 pole wifi Micro Circuit Breaker mcb Miniature Circuit Breakers
  • YUANKY 9mm 1 pole wifi Micro Circuit Breaker mcb Miniature Circuit Breakers
  • YUANKY 9mm 1 pole wifi Micro Circuit Breaker mcb Miniature Circuit Breakers

YUANKY 9mm 1 pole wifi Micro Circuit Breaker mcb Miniature Circuit Breakers

Short Description:

Advantages

Half module(9mm) is ideal to save valuable switchboard space. Required by more and moreelectrical compliance, the household also need more and more circuit breaker to protect.
It is small, but work as reliably as normal mini circuit breaker.


  • :

    • Product Detail

    Product Tags

    Technical Data
    Pole No.:1,1P+N,2.3,3P+N,4
    Rated voltage:AC 230/400V
    Rated current(A);6,10,16,20,25,32,40
    Tripping curve:B,C
    Rated short-circuit capacity(lcn):6000A
    Rated service short-circuit breaking capaciyl(lcs):6000A
    Rated frequency:50/60Hz

    Energy limiting class:3
    Electro-mechanical endurance:8000
    Contact position indication
    Connection terminal:Screw terminal      Pillar terminal with clamp
    Connection capacit:Rigid conductor up to16mm?
    Fastening torque:2.0N.m
    Installation:On symmetrical DIN rail 35mm      Panel mounting
