HW-Y2CL、HW-Y3CL、HW-Y4CL、HW-Y4CL Electromagnetic Relay

Products have serialization, basic type, improved type, functional type and so on
Working state LED indicator, coil voltage DC with LED optional infinite input
Novel structure, ingenious design, beautiful appearance, high electric resistance, with multiple patents
Improved and functional relay cover has a variety of fixed circlip design for mounting

Availability:
  • America

Type and meaning

w10

1、Enterprise Code: Haohui Electronics

2、Serial Number: Regular

3、Number of contact groups: two,three,four

4、A-normally open contact Contact Form: C-conversion type B-normally closed contact

5、mounted type: F:flange mounted type P:PCB mounted type No Letters: plug-in moudted

6、operating state:L:LED indicate No Letters:no indicate

7、auxiliary function :D/CRInhibitory protection

8、Coil Voltage:DC is for direct voltage AC is for alternating voltage

Product performance

 Model HW-Y2 HW-Y3 HW-Y4 HW-L2
Dimension ±0.5mm LongxWidexHigh 27.4×21.0×35.4mm
 Contact Form 2(A、B、C) 3(A、B、C) 4(A、B、C) 2(A、B、C)
 Contact Material AgCdo、AgSno2、Silver Alloy
Resistance Performance Of Contactor Capacity 10A
28VDC/240VAC
7A
28VDC/240VAC
5A
 28VDC/240VAC
10A
 28VDC/240VAC
Contact Resistance ≤50mΩ
Coil Powe AC 1.2VA
DC 0.9W
Coil Voltage AC 6~380VAC
DC 6~ 220VDC
 Operate time ≤15ms
 Release time ≤ 15ms
 Pick -up Voltage DC:≤75%AC:≤80%
 Drgp-out Voltage DC210%AC:230%
 Max Voltage 110%

Dielectric Strength

 Between Open Contacts
1000VAC/1min(Leakage current 1mA

    Contacs Pieces
1200VAC/1min(Leakage current 1mA

 Between Coil&Contacts
1500VAC/1min(Leakage current 1mA)
lnsulation Resistance (MΩ ≥500M2(500VDC
Service Lif Electrical  21x 105(1800OpMh
21×107(18000Ops/h)
Mechanical
 Ambient Temperature(℃ -25≈+55℃
 Humidity 35%-85%RH
Atmospheric Pressure 86~106KPa
  Vibration resistance 10~55Hz Double amplitude:1.0mm
          Terminal Type   Insert Type
         Pnotection Type   Close Type
      Suitable Socke PYF08A PYF11A PVF14A PTF08A
        Product Weight(g around 35g around 35g around 40g around 40g
Same Reference MY2 MY3 MY4 LY2

External dimensions (mm)

w11

w12

w13
